  1. #11
    RalphLambrecht's Avatar
    Join Date
    Sep 2003
    Location
    the villages .centralflorida,USA and Germany
    Shooter
    Multi Format
    Posts
    6,433
    Images
    1
    Quote Originally Posted by Ty G View Post
    The thin darkroom cloth... Porter's quit carrying it, then Freestyle Photo picked it up, now they don't have it; and Freestyle told me that the company "delta" has stopped making it.

    I know Turner bellows calls their fabric "vinyl impregnated neoprene" What is this?, Google gives me nothing.

    P.S. the commando cloth that some companies are selling is really thick and not completely lightproof (I tried a sample).

    So, does anyone know of a THIN lightproof fabric? It would most likely be rubber or vinyl coated on one side.

    Thanks, Ty
    Why not have the professionals make you one?

    http://www.custombellows.co.uk

    They do custom bellows and made one for my Linhof at 1/4 the original price.
    Regards

    Ralph W. Lambrecht
    www.darkroomagic.comrorrlambrec@ymail.com[/URL]
    www.waybeyondmonochrome.com

  2. #12

    Join Date
    Mar 2008
    Location
    Newtown, PA USA
    Shooter
    Medium Format
    Posts
    407
    True, leather would probably need a liner.

    Soloution #2, cheap and easy. Buy one of the Kalt large changing bags and cut it up. Or use a single layer of that inside the leather for a nicer finish. Attach it with a good flexible cement like 3M 8088 trim adhesive. It's designed to work on fabrics and leathers for attaching automotive trim like headliners and leather/fabric wrapped trim peices. http://www.shop3m.com/60455030050.html

    Just brainstorming here never had to make a bellows before.

  3. #13
    ic-racer's Avatar
    Join Date
    Feb 2007
    Location
    Midwest USA
    Shooter
    Multi Format
    Posts
    6,164
    The changing bag is a good idea for smaller bellows, but its not big enough for an 8x10 bellows. Obviously appropriate material is produced and sold to the people who make changing bags and bellows, but there seems to be a lack of consumer availability presently.

    Gortite might sell the raw materials, as they are an industrial supplier, not just a 'photography bellows maker.'

    However, you might consider having Gortite make the whole thing. They do give a very reasonable price for the complete bellows. When I inquired, the price was less than both Western Bellows and the place in UK.
    Last edited by ic-racer; 10-17-2009 at 03:26 PM. Click to view previous post history.

  4. #14
    Curt's Avatar
    Join Date
    Sep 2005
    Location
    Pacific Northwest
    Shooter
    Multi Format
    Posts
    4,542
    Images
    15
    The first camera I made, a 4x5 wood folder like a Wista, I used black cloth for the out side thin kraft paper on the inside and aluminum foil in the middle. It is light tight 30 years later although it doesn't get heavy use it has lasted and not broken down, I used a 3M spray adhesive and used film for the ribs.
    Everytime I find a film or paper that I like, they discontinue it. - Paul Strand - Aperture monograph on Strand

  5. #15

    Join Date
    Apr 2008
    Location
    Santa Cruz, CA
    Shooter
    Multi Format
    Posts
    167
    Images
    17
    I have some small samples of Tough Tek. It's like rubberized 1 side with a pebble texture and fiber on the other. It seems to be light proof and quite thin. I'm not sure how you would get it or any nylon to hold a tight fold. I got it in a sample pack from these guys

    http://www.owfinc.com/

    I used to make a lot of my own backpacking gear and these guys were a pleasure to deal with.

    They also have neoprene & hypalon. I'd be interested to hear if you find a good fabric.

  6. #16
    Ty G
    Couple answers; I have thought of outsourcing my bellows, I called one company, never called me back. Yes, I know there are others such as Turner bellows. The cameras I make are 1860's, so I need square corner bellows, not clipped. I have had no luck outsourcing things such as ground glass, etc. Companies don't like dealing with small guy. And the products are not "there" when I need them (two month window).

    R. Shaffer, that looks promising for an inside layer. For what its worth, I am getting in some ripstop parachute material to use for the outside layer. This will not be lightproof, but I like the watertightness of it, as I don't want someone out with one of my cameras to get caught in a storm somewhere and the bellows get water ladden and come apart.

  7. #17

    Join Date
    May 2006
    Shooter
    Medium Format
    Posts
    775
    Do a search for Barry Young and see if he would be able to build the bellows or maybe tell you where you can find material. He's up in Washington state. Might be worth the time spent.

  8. #18

    Join Date
    Mar 2008
    Location
    Taiwan
    Shooter
    Large Format
    Posts
    115
    I quit searching materials who can block light completely in one layer, instead, since bellows are made in three layers, all together they are light proof is enough to me.
    Out side layer is Chinese silk, cutting sheet as ribs, and inner is cotton cloth or darkroom nylon cloth, the glue is acrylic white glue made for fabric, they brings me very good bellows.

  9. #19
    Curt's Avatar
    Join Date
    Sep 2005
    Location
    Pacific Northwest
    Shooter
    Multi Format
    Posts
    4,542
    Images
    15
    There are two or three camps, those who have a new one made to order, $$$$$, those who find a used replacement, or get lucky at it, and those who choose to make their own.

    I've gotten lucky in finding NOS and excellent used, but can make a bellows too. If I was flush with money I'd probably have Camera Bellows or the New Camera Bellows, forgot the name, make all of mine. I bought a brand new 5x7 Canham bellows for $45.00 on the Internet, it has the metal ends attached and ready to go and is long. I'm planning to make a nice 5x7 field camera from Honduras Mahogany that has been in my shop for decades. I have the rack and pinion and gg, satin snow. I did buy some of that dark cloth from Freestyle when they had it, I'll keep it for some special projects. I found out that the Ebony cameras have Goat skin so I looked and found that I can get some in the .008 and thicker, not the same Goat skin but many different kinds. A layered bellows could be a very nice and lasting one with a skin.
    Everytime I find a film or paper that I like, they discontinue it. - Paul Strand - Aperture monograph on Strand

  10. #20
    Curt's Avatar
    Join Date
    Sep 2005
    Location
    Pacific Northwest
    Shooter
    Multi Format
    Posts
    4,542
    Images
    15
    Quote Originally Posted by salihonba View Post
    I quit searching materials who can block light completely in one layer, instead, since bellows are made in three layers, all together they are light proof is enough to me.
    Out side layer is Chinese silk, cutting sheet as ribs, and inner is cotton cloth or darkroom nylon cloth, the glue is acrylic white glue made for fabric, they brings me very good bellows.
    You did a great job on that bellows!
    Everytime I find a film or paper that I like, they discontinue it. - Paul Strand - Aperture monograph on Strand
