    Kodak Panchromatic Separation Film 2238

    2238 is a film for making archival separation positives from original color negatives. So it has to be panchromatic; the original negative is just contact printed with red, green, and blue filters in front of the light source for each of the separations. But I thought hey, panchromatic slow speed film with very fine grain... it's like Tech Pan without all the developer hassles! So I got some and finally got a chance to play with it a bit yesterday.

    It's on a clear Estar base which has a very very faint blue tinge to it after developing. (There is a blue dye somewhere in the emulsion that comes out in your developer. If you're not using one-shot developer you might want to run a prewash until the water runs clear.) The specs don't say whether it has an anti-halation layer. Because it's supposed to be contact printed it wouldn't have as much need for one. I'd say it is definitely prone to light-piping through the base, but not as badly as, say, HIE...so there is probably some less-than-normal anti-halation layer in there. It's also not quite as sharp as Tech-Pan in the end, which might be due to some slight halation. Though this would make a really dandy way to make B&W positives from B&W negatives by contacting-printing them, instead of trying to run a reversal process on the original negs!

    It's available direct from Kodak in single roll quantities, though unfortunately that roll is 2000 feet long and costs $750! Here is the spec sheet:

    http://motion.kodak.com/motion/uploa.../H-1-2238t.pdf

    I rated it at ISO 25 and ended up liking the results when developing it in ID-11 (D-76) 1:1 for 10 minutes. I also tried Rodinal 1:50 at 6:30 but to my eye that was a little grainier and probably needed a little more time to really develop the ISO 25 metered bracket shot. As you can see from the spec sheet, it can be rated and developed in a wide range of choices, which will affect contrast, etc. I was going for the less contrasty end of things.

    Here are some example shots:





























    If anyone else is interested in playing with this, I could put up some 100' rolls in the classifieds. It's definitely interesting stuff though at least in my tests so far it's not quite the miracle Tech Pan replacement.

    Kodak also sells it in 100' 70mm rolls for $105 each... though you need to buy 18 of them! But any of those folks wondering what to do with their Hasselblad 70mm backs, here's another option!

    Duncan

  2. #2
    holmburgers's Avatar
    Join Date
    Aug 2009
    Location
    Rochester NY (native KS)
    Shooter
    Multi Format
    Posts
    4,400
    Images
    2
    Fantastic post Duncan; I had no idea this film still existed.

    I might be very well be interested in a 100' roll if you get around to doing that. This might be great for, well... making separations!

  3. #3
    willrea's Avatar
    Join Date
    Dec 2007
    Location
    Yelm, Washington
    Shooter
    Multi Format
    Posts
    1,043
    Images
    20
    Quote Originally Posted by holmburgers View Post
    Fantastic post Duncan; I had no idea this film still existed.

    I might be very well be interested in a 100' roll if you get around to doing that. This might be great for, well... making separations!
    Ditto!

  4. #4

    Join Date
    Feb 2010
    Location
    Mundelein, IL
    Shooter
    35mm
    Posts
    966
    Images
    1
    OK I put up a post in the For Sale classifieds if anyone wants a roll.

    Something I thought I should point out more strongly: This is Estar base. So you'll need scissors to cut it, no way you can just tear it if that's what you're used to! On the other hand it dries insanely flat and will be dimensionally stable for basically forever, unlike acetate bases which shrink over time.

    Duncan

  5. #5

    Join Date
    Feb 2010
    Location
    Mundelein, IL
    Shooter
    35mm
    Posts
    966
    Images
    1
    Oh yeah - this film is edge marked as a 2003 batch of the stuff.

    Duncan

  6. #6

    Join Date
    Feb 2013
    Shooter
    35mm
    Posts
    5

    Fixer Proof Emulsion? HELP!

    I processed a 36 exp. roll of this film and I cannot get it to fix. No matter what i try, the film is yellow and opaque.

    I've detailed it here:

    http://www.flickr.com/groups/filmpho...57632758929143

    Any ideas?

  7. #7
    MattKing's Avatar
    Join Date
    Apr 2005
    Location
    Delta, British Columbia, Canada
    Shooter
    Multi Format
    Posts
    11,578
    Images
    59
    Try a rapid fix, rather than a regular, hardening fix like Kodafix.

    I would avoid a hardening fix as well.
    Matt

    “Photography is a complex and fluid medium, and its many factors are not applied in simple sequence. Rather, the process may be likened to the art of the juggler in keeping many balls in the air at one time!”

    Ansel Adams, from the introduction to The Negative - The New Ansel Adams Photography Series / Book 2

  8. #8

    Join Date
    Feb 2013
    Shooter
    35mm
    Posts
    5
    Have you tried this? I used regular fixer for a total time of 1 hour. I would think that if it was going to work with any form of Hypo, that would have done it.

    I do have a pound of Hypo. Not fixer, but just Hypo. No hardener. Why would the hardener be a problem?

  9. #9

    Join Date
    Feb 2010
    Location
    Mundelein, IL
    Shooter
    35mm
    Posts
    966
    Images
    1

    Kodak Panchromatic Separation Film 2238

    If it helps at all, I used Ilford Rapid Fix and did nothing special. It cleared quite quickly and thoroughly.

    Duncan

  10. #10
    MattKing's Avatar
    Join Date
    Apr 2005
    Location
    Delta, British Columbia, Canada
    Shooter
    Multi Format
    Posts
    11,578
    Images
    59
    My guess is that your "hypo" isn't working. Any chance it is actually hypo clearing agent?
    Matt

    “Photography is a complex and fluid medium, and its many factors are not applied in simple sequence. Rather, the process may be likened to the art of the juggler in keeping many balls in the air at one time!”

    Ansel Adams, from the introduction to The Negative - The New Ansel Adams Photography Series / Book 2
