    Weston Nude Solarization Technique





    As you see at Edward Weston s these two nude pictures , something is beatiful and strange. Pictures are solarized. I herebelow add an post from flickr on Weston gear ,
    technique.

    How can I solarize my prints , what was the exact recipe of two developers for that prints ? Is it possible to produce willis and clemens paper at home , pt ? Are these prints platin or azo ?
    Here is the post from flickr :

    Edward Weston's Technique

    Edward Weston brought to Mexico an 8 X 10 view camera and a 3-1/4 x 4-1/4 Graflex. His battery of lenses included an "expensive anastigmat" of unspecified make and several soft focus, or diffused focus lenses, among them a Wollensak Verito and a Graf Variable. These lenses had the characteristic that the degree of diffusion (i.e. spherical aberration) could be altered at will.

    The Variable was basically an anastigmat, fully corrected for its maximum aperture, f/3.8. By changing the distance between the front and the rear elements of this double lens, varying amounts of spherical aberration could be induced. Theoretically it thus produced either a needle sharp image or one so diffused that it hardly seemed to be produced by a lens.

    The f/4 Verito was described by its manufacturer as "a specially designed double lens... which, while it gives the desired diffused or soft optical effect, shows no distortion, double lines, or other optical imperfections, and being rectilinear gives an even diffusion over the whole plate... Will not make sharp negatives with wiry definition unless stopped down to f:8."

    When Weston wrote, on Easter, 1924, "Sharper and sharper I stopped down my lens; the limit of my diaphragm, f/32, was not enough, so I cut a smaller hole from black paper," he was referring to this characteristic of the Verito as well as to the fact that great depth of field is given with small lens openings.

    He had trouble with the Variable. Although he stopped it down to the smallest aperture, he found troublesome flares. An optometrist deduced that this was caused by the large glass surface of the f/3.8 lens. On June 24, 1924, he purchased for25 pesos a second-hand Rapid Rectilinear lens. This type of lens had long been considered obsolete, if not archaic. Years later he gave this lens to his son Brett, who has most generously presented it to the George Eastman House. It bears no maker's name. On the barrel is inscribed: "8 X 10 THREE FOCUS," and the scratched dedication, "To Brett —Dad, 1937." Examination on an optical bench proves it to be an unsymmetrical form of Rapid Rectilinear of 11-1/4 inch focal length, well made and well centered. It has no shutter — Weston used a behind-the-lens Packard shutter — but an iris diaphram marked "R. O. C. and C.CO." (Rochester Optical and Camera Co.") The smallest opening is marked "256." Measurement proves this to be the long-obsolete "Uniform System," the equivalent of f/64.

    Weston used panchromatic sheet film. This material, capable of recording all visible wavelengths — in contrast to orthochromatic emulsion, which is relatively insensitive to red and overly sensitive to blue — was an innovation in film form: it was first marketed in America by the Eastman Kodak Company only two years before Weston sailed to Mexico. Notations of exposures in the Mexican Daybook indicate that the speed of this "panchro" film would be rated today at 16 by the American Standards Association system. A portrait in full sunlight required 1/10 sec. at f/11; an open landscape was stopped down to f/32 for an exposure of 1/10 sec. with a K-l filter. He had no meter to calculate the exposure. Experience guided him: "I dislike to figure out time, and find my exposures more accurate when only felt."

    On August 24, 1924, Weston noted: "I have returned, after several years use of Metol-Hydroquinone open-tank developer, to a three-solution Pyro developer, and I develop one at a time in a tray, instead of a dozen in a tank!" This technique he used for the rest of his life. It is classic; he undoubtedly learned of it at the "photographic college" he briefly attended. The 1908 instruction manual of a similar institution — the American School of Art and Photography — recommends it as the standard developer. Weston used it with less than the usual amount of sodium carbonate. (Interestingly, the Wollensak Optical Co. advised: "Negatives made with the Verito should be fully timed, and slightly underdeveloped, using any standard developer with a minimum amount of carbonate of soda...")

    He printed on several kinds of paper. In his early years in Mexico he was especially fond of the platinum and palladium paper made by Willis & Clement, which he imported from England. This paper, which became obsolete in the 1930s, was sensitized with the salts of iron and platinum (or palladium), rather than silver. It gave soft, rich effects quite unlike any other kind of paper, and was cherished by pictorial photographers. Prints were exposed in sunlight for minutes, developed in potassium oxalate and fixed in hydrochloric acid, 'the addition of potassium bichromate to the developer gave an increased brilliance in the whites; this technique Weston used in his struggle to get prints of the dramatic white clouds which so moved him. The paper had a tendency, especially if damp, to solarize, i.e. partially reverse in the highlights, giving a dark edge instead of a light one. Printing was slow work. To make fourteen prints from as many negatives in one day, as he did on September 30, 1924, was unusual.

    On this day he noted with surprise that proof prints, made on Azo paper, gave him as much satisfaction as platinotypes. This material, which is still produced by the Eastman Kodak Company, was a typical gelatino-chloride developing-out paper exposed to artificial light. Weston always referred to it as "gaslight paper," a name given to it in the 1890s, but which was retained decades after electricity became universal.

    Although Weston preferred an 8 X 10 camera (he rejoiced in "the precision of a view box planted firmly on a sturdy tripod") he made increasing use while in Mexico of his 3-1/4 X 4-1/4 Graflex - hand held even at exposures as long as 1/10 second. To enlarge these negatives on platinum or palladium paper was tedious. An enlarged negative had to be made. First an 8 X 10 inch glass positive was made from the small negative. From this, in turn, he made a new negative, which he then printed by contact. Apparently he never printed by projection -although it was entirely practical to do so with gelatino-bromide papers which were then readily available. On his return to California he abandoned platinum and palladio papers, and settled on glossy chloro-bromide papers — which he invariably printed by contact.

    This simple technique Weston used throughout his life. It was a direct outgrowth of his formative Mexican days.
    B. N (Beaumont Newhall)
    Originally posted at 6:43AM, 27 February 2010 PST ( permalink )
    dannysoar edited this topic 9 months ago

    Mustafa Umut Sarac

    Istanbul
    Last edited by Mustafa Umut Sarac; 11-19-2010 at 08:52 AM. Click to view previous post history.

  2. #2
    holmburgers's Avatar
    Join Date
    Aug 2009
    Location
    Rochester NY (native KS)
    Shooter
    Multi Format
    Posts
    4,420
    Images
    2
    Thanks for sharing this Umut, great stuff.

  3. #3
    mjs
    mjs is offline

    Join Date
    Mar 2005
    Location
    Elkhart, Indiana (USA)
    Shooter
    Multi Format
    Posts
    1,106
    Images
    2
    The print of Charis on the Dunes would have been made in the mid 1930's; I can't recall the exact date of this particular dune trip. Bertha's knees would have been late 1920's or early 1930's, I believe. Someone with access to source materials can clarify if it's important. Both are late enough that he was using the Pyro developer mentioned above.

    A similar question was posed to Weston about the dark lines outlining Tina Modotti's figure in a Mexican photograph of the mid-1920's. Weston pointed out that there was no photographic trickery involved; it was the result of the bright sunlight, the background, and the angle of the camera lens. It was, in other words, physics. Similarly, the prints you inquired about are not solarized. I think that they are both on silver papers (contact papers, to be sure,) as I think he had stopped using platinum/palladium papers by the time these photos had been printed, but I'm not absolutely certain on that point. Hopefully someone with deeper knowledge of Weston's technique and materials can clarify. Good luck!

    Mike
    Life should not be a journey to the grave with the intention of arriving safely in a pretty and well preserved body, but rather to skid in broadside in a cloud of smoke, thoroughly used up, totally worn out, and loudly proclaiming– “Wow! What a Ride!”

    — Hunter S. Thompson

  4. #4
    Bob Carnie's Avatar
    Join Date
    Apr 2004
    Location
    Toronto-Ontario
    Shooter
    Med. Format RF
    Posts
    4,662
    Images
    14
    Actually I do not think these images are solarized, but more to point edge effects through some kind of hardening developer. The bottom image of the legs is one of my all time favorite Images.

    be interested to hear from some of the old , old timers chip in with there thoughts how he produced this wonderful effect.

  5. #5

    Join Date
    Sep 2004
    Shooter
    4x5 Format
    Posts
    196
    Nice thread Thanks

  6. #6

    Join Date
    Jan 2009
    Location
    Los Angeles
    Shooter
    Multi Format
    Posts
    1,915
    Images
    54
    I was thinking of two things that could account for the sharp borders of shade and light areas.Axis lighting and the use of Metol as one of the developing agents,Barry Thornton points out in his book Edge of Darkness that Metol has the tendency to increase density along borders of light tones next to dark tones in a negative.
    Mike

  7. #7
    keithwms's Avatar
    Join Date
    Oct 2006
    Location
    Charlottesville, Virginia
    Shooter
    Multi Format
    Posts
    6,079
    Blog Entries
    20
    Images
    129
    Hmm I never thought of these as solarized. Hmm. Maybe slightly. But frankly it wouldn't have occurred to me as something Weston would do.
    "Only dead fish follow the stream"

    [APUG Portfolio] [APUG Blog] [Website]

  8. #8

    Join Date
    Mar 2006
    Location
    San Francisco Bay Area
    Shooter
    Large Format
    Posts
    252
    Mustafa, check on the Large Format Photography Forum where I saw your post this morning, and answered with a direct quote from EW as to the effect of light on the model (Charis) during the dune series of nudes (and other of his nude studies). There were no tricks, simply an understanding of light, film, developer and paper.

    Please refer back to the LFPF, and forget the search for papers and films that no longer exist.

  9. #9

    Join Date
    Jul 2005
    Location
    USA
    Shooter
    Large Format
    Posts
    1,289
    Images
    2
    IIRC you can see the same effect in his egg image(s), and its (mostly) the lighting...

  10. #10

    Join Date
    Jan 2009
    Location
    Los Angeles
    Shooter
    Multi Format
    Posts
    1,915
    Images
    54
    Is this the limb affect.
